Safety Shower
Emergency Eye and Shower
This integrated unit provides full-body decontamination and immediate eye irrigation.
Material: Built with SS304 as standard, with options for Carbon Steel or SS316L
Performance: Shower flow exceeds 75.7 L/min, while eye wash flow is more than 11.4 L/min
Activation: Features hand pull for shower and hand-push board or foot pedal linkage for the eye wash.
Standing Eye Wash
A floor-mounted pedestal unit focused exclusively on eye and face irrigation.
Structure: Floor-standing design with a total height optimized for ergonomics.
Material: SS304 construction with ABS eye shower heads and flow regulators.
Pressure: working pressure of 0.2 MPa to 0.4 MPa.
Wall Mounted Eye Wash
A space-saving solution designed to be mounted directly onto walls, ideal for labs or narrow corridors
Material: Constructed from SS304 (optional SS316L) with optional high-visibility ABS coating
Flow Rate: Delivers more than 11.4 L/min with a built-in buffer to prevent secondary eye damage
Inlet/Drain: Standard intake size is FNPT 1/2 with an FNPT 1-1/4 drain
Variants: Available with a push-plate handle or an automatic flip-basin cover that triggers water flow upon opening
Shower Only
Dedicated high-volume showers for rapid body rinsing without the eye wash basin.
Types: Available in wall-mounted, embedded, or floor-mounted (stand-alone) configurations.
Flow Rate: High-performance nozzle delivering not less than 75.7 L/min.
Standards: Manufactured strictly according to ANSI Z358.1-2014 safety requirements.
Connections: Intake sizes range from FNPT 1 to FNPT 1-1/4 depending on the model.
